Important Notice
Because continuous adjustments and improvements are made. It is important that you use the latest versions. So download the latest version of Life Cycle Manager here before you start one of the projects below.
LATEST RELEASE
File name: otaboot.bin
Version: 2.2.5
Release date: 15 April 2022
Change log:
– Updated certificates to be identical across all versions
– Contains DigiCertGlobalRootCA and DigiCertHighAssuranceEVRootCA
– EC support put back in place
– Flow diagram still not updated
File name: rboot.bin
Version: 1.4.2
File name: blank_config.bin
Version: 1.4.2
